LaTeX
LaTeX is a computer program used for making articles, books and math formulas look good. LaTeX is well-suited for expressing mathematical formulas on electronic devices in a more human readable format, by showing them in a way similar to how they would be written by hand.
![]() | |
Original author(s) | Leslie Lamport |
---|---|
Repository | |
Platform | Cross-platform |
Type | Typesetting |
License | LaTeX Project Public License (LPPL) |
Website | www.latex-project.org |
LaTeX is used for making mathematical formulas for some articles on Wikipedia, in addition to being used within academic circles.
The writer types their article into a plain text document. A plain text document cannot have styled text, like bold or italic. When the writer wants to write styled text, they use special LaTeX commands that start with a backslash (\
). For example, the command for bold text is \textbf{This text is bold}
.
After the writer is finished writing the article, they tell LaTeX to read the document. After LaTeX is done, LaTeX makes a file that can be printed. The command \textbf{This text is bold}
would print as This text is bold.
LaTeX was first made in the early 1980s by Leslie Lamport at SRI International, who published its first manual in 1986.[1] The current version is LaTeX2e (styled ), which has been active since 1994.[2]
Example
The example below shows the LaTeX input and its corresponding output:
\documentclass[12pt]{article}
\usepackage{amsmath}
\title{\LaTeX}
\date{}
\begin{document}
\maketitle
\LaTeX{} is a document preparation system for the \TeX{}
typesetting program. It offers programmable desktop publishing
features and extensive facilities for automating most aspects of
typesetting and desktop publishing, including numbering and
cross-referencing, tables and figures, page layout, bibliographies,
and much more. \LaTeX{} was originally written in 1984 by Leslie
Lamport and has become the dominant method for using \TeX; few
people write in plain \TeX{} anymore. The current version is
\LaTeXe.
% This is a comment; it will not be shown in the final output.
% The following shows a little of the typesetting power of LaTeX:
\begin{align}
E &= mc^2 \\
m &= \frac{m_0}{\sqrt{1-\frac{v^2}{c^2}}}
\end{align}
\end{document}
|
![]() |
Academic contributions to LaTeX
In order to support mathematical typesetting, the American Mathematical Society (AMS) has made the AMS-LaTeX package.[3] AMS also founded MathJax, a Javascript extension to display mathematical formulas on web browsers, with the Society for Industrial and Applied Mathematics.[4]
Related pages
- Acaric (Developer of Cloud LaTeX)
- Beamer (LaTeX-based presentation software)
- CTAN (One of the largest LaTeX-related website)
- KaTeX (LaTeX for web browsers)
- SATySFi (A computer program expected to be an alternative to LaTeX)
